Core Parts

Motors & Actuation

Description	Datasheet	3D CAD
JGA25 Motor (5x)	`12V-200rpm`	`.STEP`
Wheel Bearing (10x)	`6806`	`.STEP`
Motor Coupler (5x)	`coupler`	`.STEP`

Description	Datasheet	3D CAD
20x20 Extrusions (10x)	`HFS5-2020`	`.STEP`
M3 T-Nuts (50x)	`HNTP5`	`.STEP`
Blind Brackets (20x)	`HBLBS5`	`.STEP`
Tabbed Brackets (20x)	`HBLFSN5`	`.STEP`

Description	Datasheet	3D CAD
M3x6 Screw (40x)	`M3x6`	`.STEP`
M3x8 Screw (40x)	`M3x8`	`.STEP`
M3x10 Screw (30x)	`M3x10`	`.STEP`
M3x12 Screw (30x)	`M3x12`	`.STEP`
M3x16 Screw (30x)	`M3x16`	`.STEP`
M3x20 Screw (30x)	`M3x20`	`.STEP`
M3 Nut (200x)	`M3-nut`	`.STEP`
M3 Insert (250x)	`M3-insert`	`.STEP`

Description	Datasheet	3D CAD
Raspberry Pi 5 (1x)	SC1111	`.STEP`
Active Cooler (1x)	`heatsink`	`.STEP`
4.3” Touchscreen (1x)	`screen`	`.f3d`
8MP Camera Module (1x)	`IMX219-160`	`.STEP`
CSI Cable 200mm (1x)	`CSI-200`	`.STEP`
DSI Cable 200mm (1x)	`DSI-200`	`.STEP`
Power Supply 5A (1x)	`PSU`	`.STEP`
Micro-SD Card (1x)	`Sandisk-64gb`	`.STEP`
Micro-SD Adapter (1x)	`SD2USB`	`.STEP`
Gamepad (1x)	`gamepad`	`.STEP`

Description	Datasheet	3D CAD
Makita Battery (1x)	`18V-2Ah`	`.STEP`
Power Receiver (1x)	`microver-PR`	`.STEP`
10A Fuse (5x)	`10A-fuse`	`.STEP`
5A Buck Converter (2x)	`XL4015-5A`	`.STEP`
2A Buck Converter (4x)	`LM2596-2A`	`.STEP`
Safety Switch (1x)	`e-stop`	`.STEP`
Male DC Jack (8x)	`PP3-050B`	`.STEP`
Female DC Jack (4x)	`PJ-038BH`	`.STEP`
PCB Female Jack (2x)	`PJ-202BH`	`.STEP`
Wago Connector (4x)	`wago`	`.STEP`
